Hyundai Kona: Rear Seat / Components and components location
Hyundai Kona (OS) 2018-2024 Service Manual / Body (Interior and Exterior) / Rear Seat / Components and components location
| Components |
| 1. Rear seat headrest 2. Rear seat back assembly [LH] |
3. Rear seat back assembly [RH] 4. Rear seat cushion assembly |
Rear Seat
...
Rear Seat Assembly Components and components location
Component Location
1. Rear seat cushion assembly
2. Rear seat back assembly
...
