| Components |
The following is the configuration of the FCA system.
| – |
Detection device (radar and camera) that can recognize potential obstacles
in the front.
|
| – |
Human-Machine Interface (HMI) to warn driver or change settings.
|
| – |
Braking system to automatically brake the car
|
FCA, contrary to FCA (Smart Cruise Control), has to work on a stationary car
so the system uses the Fusion Target system to combine radar with camera.
Description and operation
Description
–
FCA system is designed to help avoid a potential collision or reduce
its impact when drivers applies inadequate, delayed or no brakes at
all ...
Schematic diagrams
Schematic Diagram
Terminal Function
No
Function
1
-
2
C-CAN Low
...
