Hyundai Kona: Blind-Spot Collision Warning (BCW) / Blind-Spot Collision Warning Switch Components and components location

Hyundai Kona (OS) 2018-2026 Service Manual / Body Electrical System / Blind-Spot Collision Warning (BCW) / Blind-Spot Collision Warning Switch Components and components location

Circuit Diagram

Blind-Spot Collision Warning Unit Repair procedures
Removal 1. Disconnect the negative (-) battery terminal. 2. Remove the rear bumper. (Refer to Body - "Rea ...

Blind-Spot Collision Warning Switch Repair procedures
Inspection 1. Disconnect the negative (-) battery terminal. 2. Remove the crash pad garnish assembly (LH). (Re ...
