Hyundai Kona: Brake System / Rear Disc Brake Components and components location

Hyundai Kona (OS) 2018-2025 Service Manual / Brake System / Brake System / Rear Disc Brake Components and components location

Components

1. Brake pad
2. Guide rod pin
3. Guide rod pin boot
4. Caliper carrier
5. Pad retainer
6. Brake pad
7. Pad return spring

Front Disc Brake Repair procedures
Removal 1. Loosen the wheel nuts slightly. Raise the vehicle, and make sure it is securely supported. 2. Remove the front wheel an ...

Rear Disc Brake Repair procedures
Removal 1. Loosen the wheel nuts slightly. Raise the vehicle, and make sure it is securely supported. 2. Remove the rear wheel and ...
